1.install one house in 10 minutes
2.expand size:W2.48M*L5.8M*H2.5M(interior size W2.295*L5.6*H2.3m) folded size:W2.48*L5.8*H0.49M
3.one 40HC container can load 8 units
5.galvanized frame+two layers painting,hard to get rusted
6.can be stacked two levels,and add veranda,canopy,railing,stair
7.one set frame around 650kg,one set house is around 1400kg
Galvanized steel+powder coating
Color steel sandwich panels
Steel sheet with 75mm glass wool insulation
Cement fiber board/MGO board+PVC floor(optional)
Steel security door
10 units for 40'HQ
1.1 General Technical Condition
1)The structure can prevent the 8 magnitude earthquake.
2)The design of seismic grouping is the first group, the site characteristic cycle is considered 0.45s, the construction site category is considered by Class III, and the damping ratio of steel structure is 0.05. The maximum αmax of the horizontal earthquake influence coefficient is 0.04, which is calculated by 5 years.
3) Structural safety level is grade 2. The coefficient of importance is 1.0.
4) Conner fitting elevation plus or minus zero.
Normally,steel beams, steel columns, purlin are all used Q235B cold bending galvanized light steel.
strength of steel:f=215N/m2
1.3 Loading Combination
1.Calculation of floor Loading
Structure Weight 0.4 kN/m2
Dead Load Value 0.4 kN/m2
Live Load Value 3.0 kN/m2
Structure Weight 0.3 kN/m2
Dead Load Value 0.3 kN/m2
Live Load Value 0.5 kN/m2
2.Calculation of Wind loading
According to the 15 Design durable years, the basic wind pressure of wind loading is W0=0.3KN/m2
top :170*2.0mm thickness frame+two layers paint
bottom:270*2.5mm thickness frame+two layers paint
column:155*2mm thickness frame+two layers paint
5.wall&roof of foldable container house
50mm rock wool sandwich panel is standard material for wall
optional thickness 75mm,100mm.optional insulation glass wool,EPS,polyuranthane
6.floor of prefab 20ft foldable folding container house
MGO board works as the bottom floor tile
and PVC tile,carpet or wood floor and be added on top of MGO board
7.roof and ceiling of prefab 20ft foldable folding container house
steel plate+50mm glass wool insulation+steel ceiling
8.window and door of folding container house
1*40HC shipping container can load 10 units foldable house
Successful container house projects
we have done 5000+ successful container homes projects over 50 countries including australia,USA,germany,france,brazil etc.we provide one stop solution for your modular container house projects including design,production,delivery,installation etc.
1. What's your delivery time?
Normal order delivery time is 7-30 days after receive deposit.
Big order delivery time should confirm with order management dept.
2. How do you guarantee the quality of the products?
Quality first, 100% Strict quality checking before delivery.
3. How can I get the quotation of the project ?
If you have drawing, we can offer quotation accordingly.
If you don't have design, we will design some drawings for your confirmation, and then offer quotation.
4. Can you help me to purchase other things like furniture or appliance?
Yes. We provide one stop shopping arrangement for housing project.We can offer you the final solution of the house. Please send me your detail request for other facilities.
5. How to install /assemble the house?
Usually it is very easy and fast to assemble the house and there we will supply you the detailed assembling video and drawing with panel number.
6. Do you provide on-site installation service?
For big projects,we can provide installation services.The buyer should pay for the visa, two-way-air ticket, food, accomodation, transportation and 150USD/day per person salary for the installation engineer.
dingrong is specialized in developing and manufacturing all sorts of modular houses since established.It has cultivated a group of high-quality professional technicians and on-site installation team, providing all-dimensional services for customers with enterprising and pragmatic attitude.From project conception, design, manufacture, construction to installation, we will do the best of our ability to provide the most scientific,reasonable and effective solution for customers.
1. modular house manufacture with CE and ISO certificate,with professional QC and after sale team to ensure the quality
2. fast installation,can be installed in 10 minutes
3. save storage space,if you don't need to use it,can fold it .it can be unfolded and folded more than 200 times
4. competitive price with good quality:we lower the price without lower the quality to give distributor more profit to do bigger business together
5. galvanized frame+painting,hard to get rusted.wall and roof with 50mm eps insulation
6. modular design,stacked 2 levels
7. easy to load and unload in container,because will add wheels on bottom.one 40HC container can load 10 units
1. who are we?
We are based in Shandong, China, start from 2017,sell to Oceania(27.00%),Western Europe(11.00%),Southeast Asia(10.00%),North America(8.00%),South America(8.00%),Central America(8.00%),Africa(8.00%),Southern Europe(6.00%),Eastern Asia(3.00%),Mid East(3.00%),Eastern Europe(2.00%),Domestic Market(2.00%),Northern Europe(1.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
flat pack container house/Collapsible Container House/Folding Container House/Expandable Container House/pitched roof collapsible container house
4. why should you buy from us not from other suppliers?
covering an production area of 130,000 square meter,with more than 110 senior engineer in head office. They use software: Auto CAD,PKPM, 3D3S, Tekla Structures(Xsteel)V12.0.etc.provide design,manufacture,installation one-stop service.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
